Custom Precision Etching Foil Circuit for Sensor and Electronic Applications

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

📋

Basic Information

Model NO.	Custom
Machining Method	Laser Cutting, Chemical Etching
Material	Stainless Steel (SUS304, SUS316/316L, SUS301), Copper, Brass, Aluminum, Nickel, Titanium
Surface Treatments	Passivation, Ultrasonic Cleaning, Electropolishing, Plating (Nickel, Gold, Tin), Anodizing
Production Capacity	50,000 PCS / Year

🔹

Product Description

Our Custom Precision Etching Foil Circuit is manufactured using advanced chemical etching, CNC machining, and laser cutting processes. The product features ultra-fine conductive patterns, customizable geometry, and high dimensional accuracy. All shapes, hole structures, and conductive layouts can be fully customized according to design files.

✔

Key Features: High precision fine-line patterning; Burr-free processing; Complex geometry; Tight tolerance control; Suitable for micro-structures.

✔

Applications: Sensor components; Flexible circuits; Medical device parts; Automotive electronics; Aerospace precision parts; Battery connection plates.

⚙️

Technical Specifications

Parameter	Specification
Thickness Range	0.02 mm – 3.0 mm
Maximum Area	Up to 600 mm × 600 mm
Minimum Line Width	≥ 0.03 mm
Minimum Hole Diameter	≥ 0.05 mm
Tolerance	±0.01 mm (Etching) / ±0.005 mm (CNC)
Edge Condition	Burr-Free
Drawing Format	CAD / PDF / DWG / DXF

🏭

Manufacturing Capability

We provide a complete precision metal manufacturing chain, including chemical etching, high-precision laser cutting, CNC machining, and various secondary processes. Our team supports projects ranging from rapid prototyping to high-volume mass manufacturing.

📦

Packaging & Delivery

Package Type	Anti-Static Bag + Foam Protection + Export Carton
Package Size	15.00cm * 15.00cm * 2.00cm
Lead Time	7-30 days based on order quantity (1 - 5000+ Pieces)

❓

Frequently Asked Questions

1. Can you manufacture according to custom drawings?

Yes. We support full customization based on CAD drawings (DXF, DWG, PDF, AI formats). Custom slit width, aperture size, thickness, and surface treatments are all available.

2. What is the minimum feature size you can achieve?

For precision etched micro-structures, the minimum feature size can reach 0.01 mm (10 μm), depending on the material type and thickness. Typical tolerances range from ±5 μm to ±10 μm.

3. Which processing method is better: etching or laser cutting?

Chemical etching is ideal for micro-precision features requiring smooth edges and zero mechanical stress. Laser cutting is more suitable for thicker materials and larger features. We recommend the best method based on your specific design requirements.

4. Do you provide rapid prototyping?

Yes. 24-hour rapid prototyping is available for simple designs, subject to material availability and current production workload.

5. What materials are available for custom foil circuits?

Commonly used materials include SUS304 and SUS316 stainless steel, nickel, copper, and molybdenum. Other specialized materials can be evaluated upon request.

6. How do you ensure product quality?

Quality assurance begins with technical sample confirmation. During mass production, we implement strict in-process inspections and final dimensional checks before shipment to ensure compliance with your specifications.
