Basic Specifications
Product Description
High surface quality stainless steel clad steel with high strength and high performance cost ratio
Stainless steel clad steel is a combination of stainless steel and steel, offering a beautiful appearance and corrosion resistance at a low price, primarily used to replace fine stainless steel. These high-quality materials are developed and produced using innovative technology, high-end equipment, and premium raw materials, resulting in superior performance and high cost-effectiveness.
Key Advantages
1
High thermal conductivity: Aluminum has superior thermal conductivity. It can improve thermal conductivity by 35% by cladding stainless steel and aluminum materials.
2
High combination rate: We can achieve 99.99% bonding degree, no voids and bubbles through innovative technology to improve the bonding degree between materials and the density of the connection between metals.
3
Good processability: Stainless steel has good plasticity, while aluminum is soft and easy to change. Through this combination, the easy-to-form property of the material becomes more prominent.
Technical Parameters
| Clad material |
SS + Al |
SS + Al |
Al + SS |
Al + SS |
SS + Al |
| Thickness (mm) |
0.01-4.0 |
0.01-4.0 |
0.01-4.0 |
0.01-4.0 |
0.01-4.0 |
| Width (mm) |
5.0-1500 |
5.0-1500 |
5.0-1500 |
5.0-1500 |
5.0-1500 |
| Tensile strength (MPa) |
600-780 |
250-310 |
400-480 |
230-320 |
400-480 |
| Yield strength (MPa) |
540-700 |
180-250 |
340-400 |
190-280 |
340-400 |
| Elongation (%) |
≥10 |
≥25 |
≥20 |
≥25 |
≥10 |
Industry Applications
✔
Household appliances industry: Used for appliance shells and elevator decoration boards, offering low reflectivity and scratch resistance for a perfect surface.
✔
Construction industry: Provides superior surface quality and lightweight heat conduction solutions for building materials, decorative partitions, and home heat dissipation.
✔
Kitchen utensils industry: Features uniform heat conduction, lightweight design, and easy cleaning. Compatible with induction heating ranges.
Frequently Asked Questions
What is the primary benefit of stainless steel clad steel?
It combines the corrosion resistance and beauty of stainless steel with the cost-effectiveness and strength of standard steel, making it an ideal replacement for pure stainless steel in many applications.
How does cladding affect thermal conductivity?
By cladding stainless steel with aluminum, the thermal conductivity can be improved by up to 35%, which is excellent for heat dissipation and kitchenware.
What is the bonding quality between the metal layers?
Our innovative technology achieves a 99.99% bonding degree, ensuring there are no voids or bubbles between the metal layers for maximum durability.
Is this material suitable for complex forming?
Yes, the combination of stainless steel's plasticity and aluminum's softness makes the material highly processable and easy to form into various shapes.
Can these materials be used for induction cooking?
Yes, the clad design is specifically engineered to be compatible with induction heating ranges, providing uniform heat distribution.
What surface treatments are available?
The material typically comes with a coated surface treatment and is manufactured using hot-rolled techniques to ensure high surface quality.
Tags: stainless steel clad aluminum, stainless steel clad steel
